134 mm dia. spherical integral light (LS-WD130)
Red
$309.00
Zu Produktinformationen springen
134 mm dia. spherical integral light (LS-WD130)
$309.00
Uses a specially designed diffuser plate for highly uniform diffused illumination, eliminating interference caused by surface unevenness.
Features
- Specially designed diffuser for highly uniform diffused illumination
- Eliminates interference caused by surface unevenness
- Size can be customized according to different needs
Applications
- Detection of curved surfaces and concave/convex arc surfaces
- Detection of reflections on metal and glass surfaces
Specifications
| Model | LS-WD130 |
|---|---|
| Voltage | 24 V DC (12 V on request) |
| Outer diameter (mm) | 134 |
| Inner diameter / viewing window (mm) | 35 |
| Height (mm) | 69 |
| Power red (W) | 2.0 |
| Power white/blue/green (W) | 2.8 |
| Cable length (mm) | 500 |
| Mounting | 4 x M4 threaded, depth 6; 4 x dia. 3.5 through holes |
