FA lens series, 25 mm, 1.1", C-Mount (LS-VFA1-111-20M25)
$199.00
FA lens series: compact design, adjustable aperture, ultra-high resolution and minimized distortion; supports 1/1.8", 1/1.7", 2/3", 1" sensors, max sensor 1.1".
Features
- Compact design
- Adjustable aperture
- Ultra-high resolution
- High performance with minimized distortion
- Support 1/1.8", 1/1.7", 2/3", 1" sensor, max sensor 1.1"
- High resolution, high contrast and low distortion
Specifications
| Model | LS-VFA1-111-20M25 |
|---|---|
| Mount | C-Mount |
| Temperature range | -10~+50°C |
| Storage temperature range | -20~+60°C |
| Focal length | f=25mm |
| Max Diameter(RATIO) | F=1:2.8~22 |
| Picture size | 1.1" / 1" / 2/3" |
| Angle H (1.1") | 30.4° |
| Angle H (1") | 27.6° |
| Angle H (2/3") | 19.2° |
| Angle V (1.1") | 23° |
| Angle V (1") | 20.9° |
| Angle V (2/3") | 14.5° |
| Angle D (1.1") | 37.6° |
| Angle D (1") | 34.2° |
| Angle D (2/3") | 23.9° |
| Object Dimension at M.O.D H (1.1") | 119.4mm |
| Object Dimension at M.O.D H (1") | 108.5mm |
| Object Dimension at M.O.D H (2/3") | 74.6mm |
| Object Dimension at M.O.D V (1.1") | 89.5mm |
| Object Dimension at M.O.D V (1") | 81.4mm |
| Object Dimension at M.O.D V (2/3") | 74.6mm |
| Object Dimension at M.O.D D (1.1") | 186.5mm |
| Object Dimension at M.O.D D (1") | 135.6mm |
| Object Dimension at M.O.D D (2/3") | 93.2mm |
| Focus distance(min) | 0.1M |
| Flange back | 17.526mm in air |
| Back focus | 29.6mm in air |
| Filter screw size | M35.5*P0.5 |
| Front/Rear Effective Dia | dia. 20mm/dia. 19.2mm |
| Detector | 1.1" |
| Sensor format | 1.1" |
