ABS external power digital controller, 4 ch (LS-MD01C-24010-4)
$299.00
Controller section 'ABS external power digital controller' of the light controller selection manual (cards P11-P12).
Features
- Supports RS232 communication
- External power supply up to 24V
- Low trigger response time
- Supports external trigger mode
- Supports millisecond strobe and microsecond strobe
- Brightness and mode can be set manually
- 5~24V trigger, adaptable to high and low level trigger modes
- Small size, easy to install, screw mounting or C45 rail mounting
Specifications
| Model | LS-MD01C-24010-4 |
|---|---|
| Output voltage | 24V |
| Number of channels | 4 |
| Built-in power supply | NO |
| Connected light source type | 10mA~1A 24V power supply |
| Max input voltage | 24V |
| Max output voltage | 24V |
| Max current per channel | 1A/3A |
| Overheat protection | 1A none, 3A yes |
| Short-circuit protection | 1A none, 3A yes |
| Working mode | 0: normally off, 1: on, 2: millisecond strobe, 3: microsecond strobe |
| Brightness levels | 255 levels |
| Millisecond strobe time | 1~999 ms |
| Microsecond strobe time | 1~999 us |
| Communication baud rate | 9600~115200 bps optional |
| Trigger mode | Edge + level trigger |
| Operating temperature | -5~50 C |
| Luminous mode | Normally on / normally off / strobe |
| Driving mode | PWM |
| Dimension | 68 x 76.5 x 110 mm |
| Manual page code | P12 |
| Communication | RS232 |
| Mounting | Screw or C45 rail installation |
| Control | Digital (display + buttons) / RS232 |
