FA lens series, 35 mm, 1.1", C-Mount (LS-VFA1-111-20M35)
$219.00
FA lens series: compact design, adjustable aperture, ultra-high resolution and minimized distortion; supports 1/1.8", 1/1.7", 2/3", 1" sensors, max sensor 1.1".
Features
- Compact design
- Adjustable aperture
- Ultra-high resolution
- High performance with minimized distortion
- Support 1/1.8", 1/1.7", 2/3", 1" sensor, max sensor 1.1"
- High resolution, high contrast and low distortion
Specifications
| Model | LS-VFA1-111-20M35 |
|---|---|
| Mount | C-Mount |
| Temperature range | -10~+50°C |
| Storage temperature range | -20~+60°C |
| Focal length | f=35mm |
| Max Diameter(RATIO) | F=1:2.8~22 |
| Picture size | 1.1" / 1" / 2/3" |
| Angle H (1.1") | 22.6° |
| Angle H (1") | 20.6° |
| Angle H (2/3") | 14.3° |
| Angle V (1.1") | 17° |
| Angle V (1") | 15.45° |
| Angle V (2/3") | 10.7° |
| Angle D (1.1") | 28.3° |
| Angle D (1") | 25.75° |
| Angle D (2/3") | 17.86° |
| Object Dimension at M.O.D H (1.1") | 78.2mm |
| Object Dimension at M.O.D H (1") | 71mm |
| Object Dimension at M.O.D H (2/3") | 48.8mm |
| Object Dimension at M.O.D V (1.1") | 58.7mm |
| Object Dimension at M.O.D V (1") | 53.8mm |
| Object Dimension at M.O.D V (2/3") | 36.6mm |
| Object Dimension at M.O.D D (1.1") | 97.68mm |
| Object Dimension at M.O.D D (1") | 88.8mm |
| Object Dimension at M.O.D D (2/3") | 61mm |
| Distortion(TV) (1.1") | 0.02% |
| Distortion(TV) (1") | 0.02% |
| Distortion(TV) (2/3") | 0.01% |
| Focus distance(min) | 0.2M |
| Flange back | 17.526mm in air |
| Back focus | 22.9mm in air |
| Filter screw size | M35.5xP0.5 |
| Front/Rear Effective Dia | dia. 23mm/dia. 19.1mm |
| Detector | 1.1" |
| Sensor format | 1.1" |
