FA lens series, 16 mm, 1.1", C-Mount (LS-VFA1-111-20M16)
$189.00
FA lens series: compact design, adjustable aperture, ultra-high resolution and minimized distortion; supports 1/1.8", 1/1.7", 2/3", 1" sensors, max sensor 1.1".
Features
- Compact design
- Adjustable aperture
- Ultra-high resolution
- High performance with minimized distortion
- Support 1/1.8", 1/1.7", 2/3", 1" sensor, max sensor 1.1"
- High resolution, high contrast and low distortion
Specifications
| Model | LS-VFA1-111-20M16 |
|---|---|
| Mount | C-Mount |
| Temperature range | -10~+50°C |
| Storage temperature range | -20~+60°C |
| Focal length | f=16mm |
| Max Diameter(RATIO) | F=1:2.8~22 |
| Picture size | 1.1" / 1" / 2/3" |
| Angle H (1.1") | 46.3° |
| Angle H (1") | 43.6° |
| Angle H (2/3") | 30.8° |
| Angle V (1.1") | 36° |
| Angle V (1") | 33.4° |
| Angle V (2/3") | 23.3° |
| Angle D (1.1") | 55.4° |
| Angle D (1") | 53.1° |
| Angle D (2/3") | 37.9° |
| Object Dimension at M.O.D H (1.1") | 186mm |
| Object Dimension at M.O.D H (1") | 168.4mm |
| Object Dimension at M.O.D H (2/3") | 115.3mm |
| Object Dimension at M.O.D V (1.1") | 139.6mm |
| Object Dimension at M.O.D V (1") | 125.9mm |
| Object Dimension at M.O.D V (2/3") | 86.3mm |
| Object Dimension at M.O.D D (1.1") | 232.1mm |
| Object Dimension at M.O.D D (1") | 210.9mm |
| Object Dimension at M.O.D D (2/3") | 144.5mm |
| Focus distance(min) | 0.1M |
| Flange back | 17.526mm in air |
| Back focus | 22.4mm in air |
| Filter screw size | M35.5xP0.5 |
| Front/Rear Effective Dia | dia. 26.7mm/dia. 19.2mm |
| Detector | 1.1" |
| Sensor format | 1.1" |
