270 x 130 mm traditional surface light with opening (LS-FLK120240-48)
Red
$179.00
Kihagyás, és ugrás a termékadatokra
270 x 130 mm traditional surface light with opening (LS-FLK120240-48)
$179.00
Large-area uniform light emission with a high-density LED array for bright planar lighting; mainly used for contour (silhouette) imaging and large-format uniform illumination. Size can be customized.
Features
- Large-area uniform light emission
- High-density LED arrangement for high-brightness planar lighting
- Mainly used for contour imaging and large-format uniform illumination
- Size can be customized according to different needs
Applications
- Dimension measurement and shape inspection of transparent objects
- Shape inspection of electronic components and ICs
- Component counting and positioning
- Defective product detection
Specifications
| Model | LS-FLK120240-48 |
|---|---|
| Voltage | 24 V DC (12 V on request) |
| Width (mm) | 130 |
| Length (mm) | 270 |
| Height (mm) | 18 |
| Power red (W) | 15.3 |
| Power white/blue/green (W) | 17.2 |
